The instruments use the hydrostatic pressure of water to measure water depths in various environments. The instruments are used for measuring water level and are ideal for monitoring drainage levels, bore depth and river height.
Probes provide accurate long term measurements of water depths of 1m to 100m in standard ranges, with an accuracy of 0.2% full scale. The sensor is fully sealed and temperature compensated. A hermetically sealed case with a protection type IP 68 allows the pressure sensor to be immersed down to a depth of 100m. The inner vented connection cable makes pressure compensation of the measuring cell against the atmosphere possible and thus hydrostatic pressure measurement. The pressure sensor special for submersible measurement meets the electromagnetic compatibility (EMC) requirements. The mechanical fastening of the pressure sensor does not require any additional strain relief, as the construction of the cable is suitable to take a maximum tensile force of 1000 N. The cable’s individual signal wires are epoxy sealed into the casing to protect against water ingress. This probe is ideal for monitoring drainage, bore depth and river height. It can also be used to measure water with dissolved solids and other liquids.
Practical Applications:
Irrigation channel measurement and control
Aquaculture monitoring
Evaporation Monitoring
Flood Monitoring / Flood Alerts
Groundwater bore hole monitoring
Mine site environmental monitoring
Rivers and Streams Monitoring
Surface Water Monitoring
Water flow monitoring
Key Features:
- Excellent stability, high integrity and reliability
- Simple installation, easy maintenance, stable performance
- Rugged stainless steel construction.
- Digital telemetry interface.
- Excellent linearity and long-term stability.
- Wide temperature range.
- Cost effective.
Specifications:
Probe
Range: 1~100m
Accuracy: ±0.2%
Resolution: 1mm
Over pressure: 3.5m – up to 2 times fs; 10.5m – up to 2 times fs; 21m – up to 2 times fs
Output: 4-20mA or RS485
Operating Temperature: -5° to 70°C
Power: 12V DC 9.0 – 16VDC, 3mA ave, 10mA peak, 150μA sleep
Measurement Latency: 1.3 sec (approx.)
Diameter: 40mm
Length: 600mm
Weight: 2.1kg
Casing: stainless steel case with nose cone
Vented cable: 7.6mm OD, black polyurethane jacket, braided screen
Datalogger
Power: 12V DC
Power Usage: 11.5VDC to 15VDC, 6mA standby, 200mA active. 3mA ave, 10mA peak, 150μA sleep
Protocol: MODBUS
Memory: 4MB
Serial output: RS485 or RS232, Data modem and GSM/CDMA support
Display: 8 ASCII character LED
Working environment: temperature: -40 ~ +85 ℃; humidity: ≤ 95%.
Material: PVC
Size(LxWxD): 290mm x 70mm x 25mm
Weight: 850g
